- 10 -
LED Indicators
The front panel of the Moxa AWK-5222 contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is being supplied from power
input 1.
Off
Power is
not
being supplied from
power input 1.
PWR2 Green
On
Power is being supplied from power
input 2.
Off
Power is not being supplied from
power input 2.
PoE Amber
On
Power is being supplied via PoE.
Off
Power is not being supplied via PoE.
FAULT Red
Blinking
Cannot get an IP address from the
DHCP server (interval: 1 sec)
Off
There is no error condition.
STATE Green/Red
Green
Software Ready.
Blinking
Green
The AWK has been located by AWK
Search Utility (interval: 1sec)
Red
Booting or Error condition.
WLAN1
Green/Amber
Green On
WLAN1 functions in Client mode.
Blinking
Green
WLAN1’s data communication is
running in Client mode.
Amber On
WLAN1 functions in AP/Bridge
mode.
Blinking
Amber
WLAN1’s data communication is
running in AP/Bridge mode.
Off
WLAN1 is not in use.
WLAN2
Green/Amber
Green On
WLAN2 function is in Client mode.
Blinking
Green
WLAN2’s data communication is
running in Client mode.
Amber On
WLAN2 function is in AP/Bridge
mode.
Blinking
Amber
WLAN2’s data communication is
running in AP/Bridge mode.
Off
WLAN2 is not in use.
TP Port (LAN1, LAN2) LED Indicators (Port Interface)
10M Yellow
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10
Mbps
Off
TP port’s 10 Mbps link is inactive.
100M Green
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100
Mbps
Off
TP port’s 100 Mbps link is inactive.
