DA-681A Series Linux Managing Communications
3-11
ATTENTION
Click on the following links for more
information about PPP.
http://tldp.org/HOWTO/PPP
-HOWTO/index.html
http://axion.physics.ubc.ca/ppp
-linux.html
Connecting to a PPP Server over a Simple Dial-up Connection
The following command is used to connect to a PPP server by modem. Use this command for old ppp servers
that prompt for a login name (replace “username” with the correct name) and password (replace “password”
with the correct password). Note that “debug crtscts” and “defaultroute 192.1.1.17” are optional.
#pppd connect ‘chat -v ““ ATDT5551212 CONNECT ““’ ogin: username word: password’
/dev/ttyM0 115200 debug crtscts modem defaultroute 192.1.1.17
If the PPP server does not prompt for the username and password, the command should be entered as follows.
Replace “username” with the correct username and replace “password” with the correct password.
#pppd connect ‘chat -v ““ ATDT5551212 CONNECT ““’ user username password password
/dev/ttyM0 115200 crtscts modem
The pppd options are described below:
connect ‘chat etc...’
This option gives the command to contact the PPP server. The
chat program is
used to dial a remote computer. The entire command is enclosed in single quotes
because
pppd expects a one-word argument for the connect
option. The options
for
chat are given below:
-
v
verbose mode; log what we do to syslog
“ “
Double quotes
—don’t wait for a prompt, but instead do ... (note that you must
include a space after the second q
uotation mark)
ATDT5551212
Dial the modem, and then ...
CONNECT
Wait for an answer.
“ “
Send a return (null text followed by the usual return)
ogin: username word: password
Log in with username and password.
Refer to the chat man page, chat.8, for more information about the chat utility.
/dev/
Specify the callout serial port.
115200
The baud rate.
debug
Log status in syslog.
crtscts
Use hardware flow control between computer and modem (at 115200 this is a
must).
modem
Indicates that this is a mod
em device; pppd will hang up the phone before and
after making the call.
defaultroute
Once the PPP link is established, make it the default route; if you have a PPP link
to the Internet, this is probably what you want.
192.1.1.17
This is a degenerate cas
e of a general option of the form x.x.x.x:y.y.y.y. Here
x.x.x.x is the local IP address and y.y.y.y is the IP address of the remote end of the
PPP connection. If this option is not specified, or if just one side is specified, then
x.x.x.x defaults to the I
P address associated with the local machine’s hostname
(located in /
etc/hosts), and y.y.y.y is determined by the remote machine.
