Moxa DA-681A-I-DPP-T-LX [30/79] Attention

DA-681A Series Linux Managing Communications

3-14

# Keep modem up even if connection fails

persist

crtscts

modem

192.168.16.1:192.168.16.2

debug

-detach

Configure the chat script /etc/ppp/ppp-ttyM0.chat

SAY 'Auto Answer ON\n'

'' ATS0=1

Start the pppd dial-in service.

# pppd call dialin

ATTENTION

If you hope to have auto dial

-in service, you can respawn the dial-in service in /etc/inittab.

MOXA:~# echo “p0:2345:respawn:pppd call dialin” >> /etc/inittab

PPPoE

The following procedure is for setting up PPPoE:

1. Connect the DA-681A-LX’s LAN port to an ADSL modem with a cross-over cable, HUB, or switch.

2. Log in to the DA-681A-LX as the root user.

3. Edit the file /etc/ppp/chap-secrets and add the following:

“username@hinet.net” * “password” *

# Secrets for authentication using CHAP

# client server secret IP addresses

# PPPOE example, if you want to use it, you need to unmark it and modify it

"username@hinet.net" * "password" *

username@hinet.net is the username obtained from the ISP to log in to the ISP account. password is the

corresponding password for the account.

4. Edit the file /etc/ppp/pap-secrets and add the following:

“username@hinet.net” * “password” *

# ATTENTION: The definitions here can allow users to login without a

# password if you don't use the login option of pppd! The mgetty Debian

# package already provides this option; make sure you don't change that.

# INBOUND connections

# Every regular user can use PPP and has to use passwords from /etc/passwd

* hostname "" *

"username@hinet.net" * "password" *

# UserIDs that cannot use PPP at all. Check your /etc/passwd and add any
