V2401/2402 HW User's Manual BIOS Setup

4-6

On-chip Frame Buffer Size

This item determines the frame buffer size for the VGA function, and will share the system memory.

Options: 1 MB, 4 MB, 8 MB (default),

DVMT Mode

Sets the Dynamic Video Memory Technology operating mode. When set to “Fixed,” the graphics driver will

reserve a fixed portion of the system memory as graphics memory. When set to “DVMT,” the graphics driver

will dynamically allocate system memory as graphics memory, according to system and graphics requirements.

When set to “BOTH,” the graphics driver will allocate a fixed amount of memory as dedicated graphics memory,

as well as allow more system memory to be dynamically allocated between the graphics processor and the

operating system.

Options: FIXED, DVMT (default), BOTH

DVMT/FIXED Memory Size

Sets the maximum amount of system memory that can be allocated as graphics memory.

Options: 64 MB, 128 MB (default).

Boot Display

This item allows you to choose which display interface will be shown when system is booting up. Due to the

display limitation, two displays at most can be shown when booting up. If you select the default option, VBIOS

Default", the displays that have been connected will be used as the default displays.

Options: VBIOS Default (default), VGA+DVI, VGA, DVI

LVDS Function

This item allows to enable or disable the LVDS function.

Options: Disabled (default), Enabled

Panel Number

This item allows you to select the correct resolution according to your LVDS display.

ATTENTION

Note that you must select the correct resolution for your LVDS display based on your LVDS specifications, or it

will not be properly shown on your panel. When you encounter this problem, take the following steps:

1. Press the Insert key after you hear the beep.

2. Restart your computer and press the Del key while the system is booting up.

Reconfigure the VGA setting in the BIOS menu and select the correct resolution and data format for your

LVDS.
