V2401/2402 Series Linux User’s Manual System Recovery
5-8
e. Choose ### Choose THIS if you want a restoration ###
Choose the partition to backup
Note that you cannot restore a partition to itself. So every partition
but one (the destination) can be checked. Use SPACE to SELECT an
entry.
[*] ###Choose THIS if you want a restoration ###
[ ] hda1 Linux (lost+found,home,etc,media,cdrom,usr…)
[ ] hda2 Linux
[ ] sda1
<OK> <Cancel>
f. Choose the restoration source device sda1.
Choose the partition where to store the back/ where to the backup is
stored?
[ ] hda1 Linux (lost+found,home,etc,media,cdrom,usr…)
[ ] hda2 Linux
[*] sda1 (W95 FAT32 (LBA)) (V2400_V1.0_Build_09121120)
<OK> <Cancel>
