V2401/2402 Series Linux User’s Manual System Recovery
5-9
g. Enter “\” to choose the root directory of the restoration image.
Enter root directory containing your data
(eg. \mydir\PartImage)
\
<OK> <Cancel>
h. Choose V2401/2402_V1.0_Build_09121120 for the restoration image.
Action and Available images for restoration …
Choose Create_New_Image if you want a ghost-like images of
your partitions. Choose Backup_Local_Hard_Driver if prefer a
zip archive.
V2400_V1.0_Build_09121120
Create_New_Image
Backup_Local_Hard_Driver
<OK> <Cancel>
When operation is finished, turn off the computer and remove the USB disk.
ATTENTION
DO NOT turn off the power during system recovery, as the system may crash.
