DA-IRIGB-4DIO-PCI104-EMC4 Module Driver and Utility Installation
3-3
da-682a-irigb-driver
The following NEW packages will be installed:
da-682a-irigb-driver da-682a-irigb-timesync-daemon
0 upgraded, 2 newly installed, 0 to remove and 83 not upgraded.
Need to get 77.8 kB of archives.
After this operation, 0 B of additional disk space will be used.
Do you want to continue [Y/n]? Y
Get:1 http://220.135.161.42/debian/ wheezy/main da-682a-irigb-driver amd64 1.1
[67.7 kB]
Get:2 http://220.135.161.42/debian/ wheezy/main da-682a-irigb-timesync-daemon
amd64 1.2 [10.1 kB]
Fetched 77.8 kB in 0s (851 kB/s)
Selecting previously unselected package da-682a-irigb-driver.
(Reading database ... 31660 files and directories currently installed.)
Unpacking da-682a-irigb-driver (from .../da-682a-irigb-driver_1.1_amd64.deb) ...
Selecting previously unselected package da-682a-irigb-timesync-daemon.
Unpacking da-682a-irigb-timesync-daemon
(from .../da-682a-irigb-timesync-daemon_1.2_amd64.deb) ...
Setting up da-682a-irigb-driver (1.1) ...
WARNING: -e needs -E or -F
Setting up da-682a-irigb-timesync-daemon (1.2) ...
6. Verify that the driver is loaded and the time sync daemon is running.
a. Use the lsmod command to check whether the IRIG-B module is loaded.
root@Moxa:~# lsmod|grep irig
moxa_irigb 12683 1
b. Verify that the timesync daemon is running with the default configuration.
root@Moxa:~# root@Moxa:~# ps aux|grep ServiceSyncTime
root 3078 0.0 0.1 16136 1140 ? S 10:43 0:00
/usr/sbin/ServiceSyncTime -t 1 -i 10 -B
Off-line Installation
1. Download the driver from the Moxa web site at http://www.moxa.com.
2. Upload or copy the following files to the embedded computer (for example, DA-682A):
• NEW-MOXA-SYS-DEBIAN-KEY
• DA-682A-irigb-driver-1.1_amd64.deb
• DA-682A-irigb_timesync_daemon_1.2_amd64.deb
3. Install Moxa’s public key file on the embedded computer (for example, DA-682A).
root@Moxa:~# sudo apt-key add NEW-MOXA-SYS-DEBIAN-KEY
4. Install the IRIG-B driver and the timesync daemon. Follow the on-screen instruction.
root@Moxa:/home/moxa/DebianServer# dpkg -i DA-682A-irigb-driver-1.1_amd64.deb
Selecting previously unselected package da-682a-irigb-driver.
(Reading database ... 31660 files and directories currently installed.)
Unpacking da-682a-irigb-driver (from DA-682A-irigb-driver-1.1_amd64.deb) ...
Setting up da-682a-irigb-driver (1.1) ...
root@Moxa:/home/moxa/DebianServer# dpkg -i
DA-682A-irigb_timesync_daemon_1.2_amd64.deb
Selecting previously unselected package da-682a-irigb-timesync-daemon.
(Reading database ... 31661 files and directories currently installed.)
Unpacking da-682a-irigb-timesync-daemon (from
