DA-IRIGB-4DIO-PCI104-EMC4 Module Driver and Utility Installation

3-9

root@Moxa:~# mxIrigUtil -f 17 -p 3,1

Set DO 3 = 1

The following command example displays the digital input interface.

root@Moxa:~# mxIrigUtil -f 18 -p 0

Get DI 0 = 0

root@Moxa:~# mxIrigUtil -f 18 -p 1

Get DI 1 = 0

root@Moxa:~# mxIrigUtil -f 18 -p 2

Get DI 2 = 0

You can edit the /etc/init.d/mx_irigb.sh script to configure the IRIG-B utility. For example, if you want to

set the IRIG-B digital output interface, remove the ‘#’ symbol from the /usr/sbin/mxIrigUtil line and

configure the MX_IRIGB_UTIL_OPTS parameter. The following figure shows an example.

root@Moxa:~# sudo vi /etc/init.d/mx_irigb.sh

...

MX_IRIGB_UTIL_OPTS="

-f 15 -p 1,1,2,0"

...

case "$1" in

start)

...

# If you need the IRIG-

B signal output, you should remove the # in from

of the following line.

/usr/sbin/mxIrigUtil $MX_IRIGB_UTIL_OPTS > /dev/null 2>&1

...

Installing the IRIG-B Driver in Windows 7

1. Log into the embedded computer as an administrator.

2. Download the installation files from the Moxa web site at http://www.moxa.com

3. Copy the driver and utility files to the embedded computer.

4. Double-click the IRIG-B driver installation file.

5. When the welcome screen appears, click Next.
