DA-710 Series Hardware Manual Introduction

1-2

Overview

The DA-710 computer is based on the Intel x86 processor, supports VGA, and comes with 4 Ethernet ports, 2

RS-232 serial ports, CompactFlash, and USB. The DA-710 comes in a standard 19-inch, 4U high form factor,

making it an ideal platform for industrial applications.

The DA-710 comes with 4 PCI slots for inserting expansion modules. Moxa provides a variety of communication

modules, including an 8-port RS-232/422/485 module, a 4-port 10/100 Mbps LAN module, an 8-port

RS-422/485 module, an 8-port switch module, and a universal PCI expansion module. This friendly modular

design gives users the advantage of being able to swap out modules quickly and easily.

The DA-710 runs Linux or Windows Embedded Standard 2009 (pre-installed), providing a friendly environment

for developing sophisticated application software. Moxa provides extensive software support to help

programmers easily develop bug-free code quickly and at a lower cost.

Model Descriptions and Package Checklist

The DA-710 Series includes the following models:

DA-710-LX

x86-based rackmount embedded computer with 2 RS-232 ports, 4 LANs, 4 PCI slots, 4 DIs, 4 DOs, VGA,

CompactFlash, USB, Linux 2.6

DA-710-XPE

x86-based rackmount embedded computer with 2 RS-232 ports, 4 LANs, 4 PCI slots, 4 DIs, 4 DOs, VGA,

CompactFlash, USB, Windows Embedded Standard 2009

Each model is shipped with following standard items

• Quick Installation Guide

• Document & Software CD or DVD

• Ethernet Cable: RJ45 to RJ45 cross-over cable, 100 cm

• Product Warranty Statement

Optional Expansion Modules

• DA-SP08-I-DB: 8-port RS-232/422/485 serial port module with isolation protection, DB9 connectors.

• DA-SP08-DB: 8-port RS-232/422/485 serial port module, DB9 connectors.

• DA-SP08-I-TB: 8-port RS-232/422/485 serial port module with isolation protection, terminal block

connectors.

• DA-SP38-I-TB: 8-port RS-422/485 serial port module with isolation protection, terminal block connectors.

• DA-SW08-RJ: 8-port 10/100 Mbps unmanaged switch module.

• DA-LN04-RJ: 4-port 10/100 Mbps LAN module.

• DA-UPCI-DK: 5V standard PCI extension kit.
