EM-2260-CE User’s Manual Introduction
Features
The EM-2260 Embedded Module/EM-2260 Development Kit has the following features:
y Cirrus Logic EP9315 ARM9 CPU, 200 MHz
y 128 MB RAM on-board, 32 MB Flash Disk
y Graphical interface for external VGA output connection
y 4 high speed TTL serial ports
y Dual 10/100 Mbps Ethernet for network redundancy
y 8+8 DI/DO
y Support EIDE interface and USB 2.0 Host
y Ready-to-Run WinCE 6.0 or Linux platform
y Full-function development kit for quick evaluation and application development
ATTENTION
The dual Power Circuit, extra LAN controller and CF card socket are supported only by
EM-2260 Development Kit. EM-2260 embedded module connects to all the input/output
peripherals through signals of two 100-pin connectors.
Specifications
EM-2260 embedded module supports all the peripherals through signals of two 100-pin connectors,
CN1 and CN2. Differences of EM-2260 embedded module and EM-2260 Development Kit will be
specially specified.
System
CPU:
Cirrus Logic EP9315 ARM9 CPU, 200 MHz
DRAM:
128 MB onboard
Flash:
32 MB Flash onboard
Storage Expansion:
EM-2260: EIDE Interface signals support up to 2 external devices
connection
EM-2260 Development Kit: CompactFlash socket x 1 for storage expansion
USB:
EM-2260: Signals support USB 2.0 Host (OHCI) x3
EM-2260 Development Kit: USB 2.0 Host (OHCI) x 2, Type A connector
Console/Debugging Port:
RS-232 x 1 (TxD, RxD, GND), 4-pin header output
LED
EM-2260 Development Kit: System: Power x 1, Ready x 1, Storage x 1
LAN: 10M/Link x 2 (on connector), 100M/Link x 2 (on
1-5
