IA260-261-262 EM-2260 LX User’s Manual Managing Embedded Linux
Loading Factory Defaults
To load the factory default settings, you must press the reset-to-default button for more than 5
seconds. All files in the /home & /etc directories will be deleted. Note that while pressing the
reset-to-default button, the Ready LED will blink three times, and then turn off. It takes about one
minute for the factory defaults to fully load. For users who have logged onto the computer, please
note that they will be forcibly logged out when the factory defaults are loaded and the systems
start to reboot.
Enabling and Disabling Daemons
The following daemons are enabled when the IA260/IA261/IA262/EM-2260 boots up for the first
time.
snmpd ..........SNMP Agent daemon
telnetd..........Telnet Server daemon and Client
inetd.............Internet Daemons
ftpd...............FTP Server daemon and Client
sshd ..............Secure Shell Server daemon
httpd ............Apache WWW Server daemon
Type the command “ps ” to list all processes currently running.
192.168.3.127 – PuTTY
root@Moxa:~# cd /etc
root@Moxa:/etc# ps
PID Uid VmSize Stat Command
1 root 532 S init [3]
2 root SWN [ksoftirqd/0]
3 root SW< [events/0]
4 root SW< [khelper]
13 root SW< [kblockd/0]
14 root SW [khubd]
24 root SW [pdflush]
25 root SW [pdflush]
27 root SW< [aio/0]
26 root SW [kswapd0]
604 root SW [mtdblockd]
609 root SW [pccardd]
611 root SW [pccardd]
625 root SWN [jffs2_gcd_mtd3]
673 root 500 S /bin/inetd
679 root 3004 S /usr/bin/httpd -k start -d /etc/apache
682 bin 380 S /bin/portmap
685 root 1176 S /bin/sh --login
690 root 464 S /bin/snmpd
694 nobody 3012 S /usr/bin/httpd -k start -d /etc/apache
695 nobody 3012 S /usr/bin/httpd -k start -d /etc/apache
696 nobody 3012 S /usr/bin/httpd -k start -d /etc/apache
697 nobody 3012 S /usr/bin/httpd -k start -d /etc/apache
698 nobody 3012 S /usr/bin/httpd -k start -d /etc/apache
701 root 352 S /bin/reportip
714 root 1176 S -bash
726 root 436 S /bin/telnetd
727 root 1180 S -bash
783 root 628 R ps
root@Moxa:/ect#
3-5
