MC-7130-MP Series Hardware Introduction

2-4

LED Indicators

LED Name LED Color LED Function

Power

(on front panel)

Green Power is on and functioning normally

Off Power is off or power error exists

Storage

(on front panel)

Red (on) Storage disk is functioning properly

Red (blinking) Storage disk is accessing data

Off No activity

LAN (1 to 4)

(on connectors)

Green 100 Mbps Ethernet mode

Yellow 1000 Mbps (Gigabit) Ethernet mode

Off No activity or 10 Mbps Ethernet mode

Real Time Clock

The embedded computer’s real-time clock is powered by a lithium battery. We strongly recommend that you

NOT replace the lithium battery on your own. If the battery needs to be changed, contact the Moxa RMA service

team at

http://www.moxa.com/rma/about_rma.aspx.

ATTENTION

Used batteries are environmentally hazardous materials. Dispose of them in the proper manner.

WARNING

There is a risk of explosion if the wrong type of battery is used. To avoid this potential danger, always be sure

to use the correct type of battery. Contact the Moxa RMA service team if you

have any questions about

replac

ing your battery.
