MC-7130-MP Series BIOS Setup
4-17
3. When boot up finishes, DOS screen will show up. Go to the directory where the upgrade file is located. For
example, if the upgrade file is stored in the MC_7130 folder, type cd MC_7130
C:
\cd MC_7130
4. Run the upgrade program by typing MC7130S03.exe. Please note that the upgrade filename may vary
depending on the versions.
C:
\ MC_7130>MC7130S01.exe
5. The upgrade program will be automatically performed. Please wait until the procedure to be finished.
6. When the upgrade is finished, the computer will automatically reboot. You may check the BIOS version in
Main page of the BIOS Setup
