MPC-2000 Series Hardware Introduction
1-3
NOTE
Please notify your sales representati
ve if any of the above items are missing or damaged.
Product Features
• 19-inch, 24-inch, or 26-inch display screen
• Color calibration for ECDIS compliance
• Fanless design
• SavvyTouch display controls
• 3rd Generation Intel® Core™ (Default: Celeron® 1047UE, 1.40 GHz with Intel® HD Graphics)
• Built-in NMEA 0183 and software selectable RS-232/422/485 interfaces
• Dual AC/DC power supply units
Hardware Specifications
MPC-2260 Models
Computer
CPU:
lntel Celeron® Processor 1047UE (2M Cache, 1.40GHz)
OS:
Windows 7 Professional, Windows XP Embedded, Windows Embedded Standard 7, Windows XP SP3
System Chipset:
Intel HM65
System Memory:
8 GB capacity, 4 GB pre-installed: 1 slot of 4 GB DDR3-1600 204 pin SO-DIMM SDRAM
USB:
4 bootable USB 2.0 hosts, type A connectors
Sto
rage: 2 SATA III interfaces: 6 Gbps, 2.5” removable storage trays
BIOS:
64 Mbit Flash BIOS with SPI, ACPI
Graphics Controller:
Intel HM65 Express chipset built in
Video Outputs:
DVI-D x 1, VGA x 1 (female)
Other Peripherals
Audio: line in/out, 3.5 mm mini jack
KB/MS:
2 PS/2 interfaces supporting standard PS/2 keyboard and mouse
Display
Panel Size:
26” viewable image size
Panel Type:
MVA
Aspect Ratio:
16:10
Pixels:
1920 x 1200 (WUXGA)
Pixel Pitch (RGB):
0.2865 (H) x 0.2865 (V) mm
Response T
ime: 15 ms (gray to gray)
Contrast Ratio:
1500:1
Light Intensity:
300 cd/m
2
Viewing Angles:
176˚/176˚
Active Display Area:
550.08 (H) x 343.8 (V) mm
Max Colors:
16.7M (8 bit color)
Resolution:
• VGA: 640 x 480
• SVGA: 800 x 600
• XGA: 1024 x 768
• S
XGA: 1280 x 1024
• WSXGA+: 1920 x 1080
• WUXGA: 1920 x 1200
