Marine Displays and Computers
1
www.moxa.com
MD-226 Series
Introduction
26-inch wide screen marine display, 16:10 aspect ratio,
full HD 1920 x 1200 resolution
The MD-226 series of marine displays comes with full range dimming,
wide viewing angles, and optional optical bonding. These displays are
built with a small-profile modular design that allows easier integration
into industrial marine systems, reducing deployment costs and overall
time-to-market.
The innovative and user-friendly SavvyTouch display controls offer
several unique features not found on any other marine display console:
a proximity sensor for convenient adjustments in dark conditions, an
info button for immediate updates on hardware status, and a quick-
switch to adjust between day, dusk, and night-time ECDIS modes (for
color-calibrated ECDIS models only).
The MD-226 series displays are compliant with IEC 60945, DNV,
and IACS-E10, verifying their resilience and durability in maritime
conditions. Their IP54 rated enclosure provides additional protection
against dust and moisture above and beyond the limits established by
these international standards bodies.
ECDIS-approved models are also available, offering an excellent HMI
solution for ECDIS charting and navigation stations.
Appearance
SavvyTouch Display Control Buttons
26-inch Panel
24 VDC
Power Input
100 to 240 VAC
Power Input
VGA/DVI-D
Input
RS-232
RS-422/485
Buzzer
› 26-inch Full-HD display, 16:10 aspect ratio
› High quality LCD with LED backlight
› Color calibrated for ECDIS compliance
› Full range dimming, 0 to 100%
› SavvyTouch™ display controls
› Built-in RS-232/422/485 interfaces
› Dual power supplies (AC & DC)
› IP54 (front) / IP22 (rear) rated
› Optical bonding available on request
