Moxa MD-226X [3/3] Ordering information

Marine Displays and Computers

Ordering Information

We recommend taking the following precautions to minimize heat

build-up within the display:

• Position the display within ±40° of the vertical.

• Install an external fan to increase airﬂow upwards through the

display if (a) the display is not positioned within ±40° of the

vertical, (b) the ambient temperature exceeds 25°C, or (c) the

display is used in a location with minimal ventilation.

Important Safety Precaution:

Even though the display is rated to operate within the IEC 60945

standard of -15 to 55°C, it is best to ensure that the ambient

temperature does not exceed 25°C. Doing so will increase the life

of your display and minimize service costs.

Available Models

MD-226X: 26-inch display with 16:10 aspect ratio, 1920 x 1200 resolution, LED backlighting,

RS-232/422/485 serial ports, dual-power supply (AC/DC)

Optional Accessories (can be purchased separately, for AC power input)

PWC-C13US-3B-183: Power cord with 3-pin connector, USA plug

PWC-C13EU-3B-183: Power cord with 3-pin connector, Euro plug

PWC-C13UK-3B-183: Power cord with 3-pin connector, British plug

PWC-C13AU-3B-183: Power cord with 3-pin connector, Australian plug

PWC-C13CN-3B-183: Power cord with 3-pin connector, Chinese plug

Optional Mounting/Bracket Kits (can be purchased separately)

MPC-MD-2-24-26-DMTK w/o hinge: Desktop mounting kit without hinge

MPC-MD-2-24-26-DMTK w/ hinge: Desktop mounting kit with hinge

Package Checklist

• MD-226 display

• VGA cable

• DVI-D cable

• 2-pin terminal block x 1

• 5-pin terminal block x 2

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card
