ioMirror E3210 Introduction
1-8
Hardware Overview
Please note that the LCD display module is an optional accessory.
Reset Button – The reset button is used to load factory defaults. Use a pointed object, such as a straightened
paper clip or toothpick, to hold the reset button down for 5 seconds. The Ready LED will turn red as the factory
defaults are loaded and will change to green when the operation is complete.
Pin Assignments
Ethernet (CN1)
Pin Signal
1 Tx+
2 Tx-
3 RX+
6 Rx-
Power (TB1)
