ioMirror E3210 Using the Web Console
3-3
Quick Reference
The following is a quick reference guide to the pages in the ioMirror’s web console. Details for each page are
presented later in this chapter.
Overview
→ Show model name, serial number, etc.
Basic Settings
→
Set time, time server
Network Settings
General Settings
→
Set name, location, DNS
Ethernet Configurations
→
Set IP address, netmask, gateway
I/O Settings
DI Channels
→
Configure digital input channels
DO Channels
→
Configure digital output channels
ioMirror Settings
→
Configure channel/module mapping, alarm system
System Management
Accessible IP Settings
→ Filter access by IP address
Network Connection
→
Show TCP connections from different hosts
LCM
→
Show LCM status
Change Password
→
Set password
Load Factory Default
→
Restore factory default settings
Save/Restart
→ Save all changes and reboot
Basic Settings
On the Basic Settings page, you may set the system time or provide the IP address of a time server for time
synchronization.
