VPort P06-1MP-M12 System Configuration

4-25

Privacy Mask

In some conditions, you may want to block part of the view so that your surveillance system won’t include some

private video information when displaying live video or video playback.

Privacy Mask

Setting Description Default

Enable Enable the privacy mask function Off

Mask 1/2/3 Enable up to 3 different privacy mask areas. O

nce enabled, you

can drag the masked area directly into the camera scene.

unchecked

NOTE

Only use this function when you want to mask parts of the scene. You cannot recover masked video either when

viewed live or during playback.

Video Performance

The VPort P06-1MP-M12 can send a maximum of three simultaneous video streams: two H.264 and one MJEPG.

In fact, the VPort P06-1MP-M12 has two encoder engines. The first encoder engine can generate one

completely independent H.264 video stream, which means that its resolution, FPS, and video quality can be

configured independently. The second encoder engine can generate one H.264 video stream and one MJPEG

video stream. Because both the H.264 and MJPEG video streams come from the same encoder engine, their

resolutions must be the same, but the FPS and the Video Quality can be configured separately. The

administrator can set the Resolution, Max. Frame Rate, and Video Quality on this web page.
