VPort P06-1MP-M12 System Configuration

4-26

Resolution Type

Setting Description Default

NTSC or PAL Choose NTSC or PAL resolution typefor your system NTSC

Streams

Setting Description Default

Enable the video

streams

Enables the VPort to send this video stream. Enable stream 1 for

H.264;

Enable stream 2 for

MJPEG

Codec Type

This codec type shows the codec of each video stream.

Resolution

The VPort P06-1MP-M12 supports 7 different resolutions: 1MP, HD, SVGA, Full D1, 4CIF, VGA, CIF

Setting Description Default

Select the image size 6 image resolutions (sizes) are provided. The

administrator can choose each option with NTSC or PAL

modulation.

1280 x 720 for stream1;

720 x 480 for stream 2

Resolution NTSC PAL

1MP 1280 x 800 1280 x 800

HD 720P 1280 x 720 1280 x 720

SVGA 800 x 600 800x 600

Full D1 720 x 480 720 x 576

4CIF 704 x 480 704 x 576

VGA 640 x 480 640 x 480

CIF 352 x 240 352 x 288

QCIF 176 x 112 176 x 144

NOTE

1280 x 800, 1280 x 720, and 800 x 600 are only available in stream 1. QCIF (176 x 112 or 176 x 144) is only

available in stream 2.

The maximum resolution for stream 2 is full D1 resolution.

Max. FPS (Frame per second)

Setting Description Default

Maximum frame rate The maximum frame rate is different to accommodate

different

modulations of video input. Administrators can also set up the

maximum frame rate to optimize bandwidth use.

NTSC: 1, 3, 5, 10, 15, 20, 25, 30

PAL: 1, 3, 5, 8, 12,16, 20, 25

30 for NTSC, 25 for

PAL

NOTE

Frame rate (frames per second) is determined by the resolution, image data size (bit rate), and transmission

traffic status. The Administrator and users can check the frame rate status in the FPS Status on the VPort’s web

homepage.
