Moxa VPort P16-1MP-M12-CAM80-CT [35/64] Lldp not supported by all vports

IP/Name

Enter the IP address or name of the Trap Server used by your

network.

Trap Community Use a community string match for authentication;

Modbus is a serial communications protocol that is often used to connect a supervisory computer with a remote

terminal unit (RTU) in supervisory control and data acquisition (SCADA) systems. To transmit Modbus over a

TCP/IP network, a standard Modbus/TCP protocol is provided. With the support of the Modbus/TCP protocol,

the SCADA/HMI system can directly communicate with the VPort to acquire its operational status.

advertisement method, and allows each networking device to periodically send its system and configuration

information to its neighbors. Because of this, all LLDP devices are kept informed of each other’s status and

configuration, and with SNMP, this information can be transferred to Moxa’s MXview for auto-topology and

network visualization.

From the VPort’s web interface, you can enable or disable LLDP, and set the LLDP transmit interval. In addition,

you can view each VPort’s neighbor-list, which is reported by its network neighbors. Most importantly, enabling

the LLDP function allows Moxa’s MXview to automatically display the network’s topology and system setup

details for the entire network.
