DAB (Optional)
100-EN
PTY (Programme Type) Tuning
1 Press F
•
SETUP and the FUNC indicator
switches off.
2 Press any one of the multi function buttons
1 to 3.
The FUNC indicator switches off, and the
multifunction mode is displayed.
3 Press multi function (SEARCH) within 5
seconds.
The unit switches to PTY search mode.
4 Press 1 ( ) or 5 ( ) to select your desired
programme type.
T.INFO
F
•
SETUP
5( )
1( )
2(ENT)
Multi function buttons 1 to 3
