RDS
58-EN
Setting RDS Reception Mode and Receiving
RDS Stations
The RDS (Radio Data System) is a radio information system using the 57 kHz subcarrier of regular
FM broadcast. The RDS allows you to receive a variety of information such as traffic information,
station names, and to automatically re-tune to a stronger transmitter that is broadcasting the same
programme.
1 Press F
•
SETUP and the FUNC indicator
lights up green.
2 Press 1/AF to activate the RDS mode.
3 Press or to tune in the desired RDS
station.
1/AF
F
•
SETUP
