9-EN
When operating the DVI-9990R with the supplied remote control, change the position of the switch
on the rear side of the remote control to “H/U”.
Detaching the Front Panel
1 Press and hold SOURCE/POWER for more
than 3 seconds to turn off the power.
2 Press (Release) at lower left corner until
the front panel pops out.
3 Grasp the left side of the front panel and pull it
out.
• The front panel may become hot in normal usage
(especially the connector terminals), this is not
malfunction.
• To protect the front panel, place it in the supplied
carrying case.
SOURCE/POWER
POWER
Basic Operation
