DAB (Optional)
102-EN
Setting the Announcement Select Mode
1 Press T.INFO for at least 2 seconds to turn
ON the Announcement Select mode.
2 Press F
•
SETUP for more than 3 seconds.
3 Press 1 ( ) or 5 ( ), select “EX-BOX”, and
press 2 (ENT).
4 Press 1 ( ) or 5 ( ), select “ANNOUN”, and
press 2 (ENT).
2(ENT)T.INFO
F
•
SETUP
5( )
