Nec U300X [12/82] Introduction
![Nec U300X [12/82] Introduction](/views2/1205525/page12/bgc.png)
5
... English
Introduction
Power Cord (3m)x1
Computer Cable (VGA) (3m)
(P/N:79TC3081)
Remote Control
(P/N:79TC3051)
Projector
Package Overview
This projector comes with all the items shown below. Check to
make sure your unit is complete. Contact your dealer immedi-
ately if anything is missing.
Due to the differ-
ence in applications
for each country, some
regions may have dif-
ferent accessories.
Documentation:
NEC Projector CD-ROM
(P/N: 7N951531)
Quick Setup Guide (P/N:
7N8N1121)
Important Information (For
North America: 7N8N1101)
(For Other countries than
North America: 7N8N1101
and 7N8N1111)
For North America:
Registration Card
Limited Warranty
Batteries (AAAx2)
The cable cover
is attached to the
projector at the time of
shipment. When you
use the projector for
the rst time, remove
the cable cover before
connecting cables. Refer
to page 9 for removing
and attaching the cable
cover.
For Europe:
Guarantee Policy
For customers in Europe:You will nd our current valid Guarantee
Policy on our Web Site:www.nec-display-solutions.com
Do not throw
away the mirror cover,
carton, and packing
materials.
US (P/N:79TC3011) EU (P/N:79TC3021)
