![Loewe Concept L42 [11/24] Sort stations](/views2/1020608/page11/bgb.png)
11
Manual station adjust
You can also adjust a station manually.
Press
MENU
.
The “TV menu” is displayed.
Select the option “Programmes” with v / V
and press B.
Select the option “Manual adjust” with v / V
and press B.
Select an option with v / V and change the
desired selection with b / B
Manual station adjust
Store at preset
Range
Channel
Frequency
Name
TV standard
Via decoder
2
VHF/UHF
7
189.25 MHz
ZDF
PAL BG
No
Store at preset: Displays the station´s chan-
nel slot.
Range: Selects the tuner’s receiver range
“VHF/UHF” or “Cable”.
Channel: Selects the reception channel (also
possible by direct numeric input).
Frequency: Enters the station frequency (also
possible by direct numeric input).
Name: Enter or change station name. Select
the cursor position with b B and set the
characters with v V.
To terminate entry of the name, press B again
after the last (5
th
) letter.
TV Standard: Defi nes the TV standard of the
received station.
Decoder: Determines whether a decoder is
connected to the AV-1 socket (see page 20).
1.
2.
3.
4.
Sort stations
You can change the order of stations later on.
Proceed as described under section 1 and 2
“Manual station adjust”.
Select the option “Sort” with v / V
and press B.
Select the station you want to move and press
OK. The selected station slot is now displayed
in blue.
OK
MENU
END
Sort station
End
Back
Select and move
with OK.
1 ARD
2 ZDF
3 SAT1
4 KABEL
5 RTL2
6 PRO7
7 RTL
8 VOX
9 3SAT
10 WDR3
11 BR
12 NDR
13 VIVA
14 DSF
15 EUROS
16 N-TV
17 SRTL
18 TV5
19 TRT1
20 PHOEN
Select the position with v V b B to which
you want to move the selected station and
then press OK.
OK
MENU
END
Sort station
End
Back
Select and move
with OK.
1 ARD
2 ZDF
3 SAT1
4 KABEL
5 RTL2
6 RTL
7 PRO7
8 VOX
9 3SAT
10 WDR3
11 BR
12 NDR
13 VIVA
14 DSF
15 EUROS
16 N-TV
17 SRTL
18 TV5
19 TRT1
20 PHOEN
1.
2.
3.
4.
Delete stations
You can also delete stations.
Proceed as described under section 1 and 2
“Manual station adjust”.
Select the option “Delete” with v / V and
press B
OK
MENU
END
Delete stations
End
Back
Select and delete
with OK
1 ARD
2 ZDF
3 SAT1
4 KABEL
5 RTL2
6 PRO7
7 RTL
8 VOX
9 3SAT
10 WDR3
11 BR
12 NDR
13 VIVA
14 DSF
15 EUROS
16 N-TV
17 SRTL
18 TV5
19 TRT1
20 PHOEN
Select the station you want to delete with v
V b B and press OK.
OK
MENU
END
Delete stations
End
Back
Select and delete
with OK
1 ARD
2 ZDF
3 SAT1
4 KABEL
5 RTL2
6 PRO7
7 RTL
8 VOX
9 3SAT
10 WDR3
11 BR
12 NDR
13 VIVA
14 DSF
15 EUROS
16 N-TV
17 SRTL
18 TRT1
19 PHOEN
20 QVC
1.
2.
3.
Initial installation
