Loewe Concept L42 [22/24] Technical specifi cations
![Loewe Concept L42 [22/24] Technical specifi cations](/views2/1020608/page22/bg16.png)
22
General
Concept L 42 Item No. 64403
Power supply AC 115-240V, 50/60 Hz
Power consumption During operation: 350 W, standby: 5 W
Dimensions (Display). 1167 x 628 x 94 mm (W x H x D)
Dimensions (with table stand). 1167 x 707 x 218 mm
Weight (approx.) 35 kg (with table stand)
Operating temperature +5 °C ...+35 °C
Humidity 5 % ... 80 % (no condensation) @ 40°
Atmospheric pressure 800..1100 HPa (0...2000 m NN)
Screen
Display-technology Plasma
Image format 16 : 9
Image diagonal Visible 106 cm
Pixel-format 852 x 480
Contrast ratio 3000 : 1
Angle of viewing > 160°
Luminance max. 1000 cd/m2
TV functions
TV-standard RF-Mode PAL: B/G, I, DK
Secam: B/G, DK/K1, L/L
TV-standard AV-Mode PAL: B/G, I, DK, M, N
Secam: B/G, DK/K1, L/L
NTSC: M 4, B/G 4, D/K 4, NTSC-V (4,43)
Progressive Scan
Tuner VHF/UH/cable 47... 861 MHz
Station slot memory TV / AV 99 / 6
Teletext standard TOP/FLOF, Level 2.5
Teletext page memory 2100
Picture in Picture Splitscreen: TV + Teletext
Smal picture (PIP): TV + AV, TV + PC
TV-format RF/AV-Mode 16 : 9, 4 : 3, Panorama, Auto
Zoom (130%), User Zoom (40...140%)
PC-Modes
Resolution 640x480, 720x400, 800x600, 1024x768
DVI 1.0
Pixel Clock VGA: max. 140 MHz, DVI: max 110 MHz
Horizontal frequency range 30 kHz...80 kHz
Vertical frequency range 50 Hz...90 Hz
TV-format in PC-Mode 1 : 1, User Zoom (40...140%), Auto
Sound
Sound standard Mono/Stereo/bilingual
Nicam B/G, L,I
Rated audio power 20 W
Speaker 4
Connections
ANTENNA IN Antenna / cable IEC 75 Ohm
RF IN / OUT PIP Tuner IN/OUT
AV 1 SCART socket 1
Video IN FBAS (VHS / 8 mm), RGB
Video OUT FBAS (VHS / 8 mm)
Audio IN/OUT L / R
AV 2 SCART socket 2
Video IN FBAS (VHS / 8 mm)
Video OUT FBAS (VHS / 8 mm)
Audio IN/OUT L / R
AV 3 S-Video socket S-VHS / Hi 8 Mini-DIN S-Video-IN
AV 4 Video socket CVBS/FBAS-Signal / VHS Cinch Video-IN
AV 5 YUV socket (Component IN)
Cinch Y-signal (CVBS)
Cinch V-signal (Cr/Pr)
Cinch U-signal /Cb/Pb)
Service-socket D-SUB 9 pole RS232
AV 6/7 RGB/DVI socket DVI-I Video Digital input / VGA
Audio
2 x Cinch L / R Audio OUT
2 x Cinch L /R Audio IN AV 4/5
2 x Cinch L /R Audio IN AV 6/7
2 x Cinch L /R Audio IN AV 3
SUB OUT Subwoofer OUT
Design and technical specifi cations are subject to change without notice.
Technical Specifi cations
32241 Concept L42_Buch_GB.indd 2232241 Concept L42_Buch_GB.indd 22 11.02.2005 14:09:44 Uhr11.02.2005 14:09:44 Uhr
