CS261 RS-232 Control Tool

EDID Mode

The EDID Mode command allows you to set EDID settings. Use the Formula

- to set Parameters - to create a Command.

Formulas:

Command + Control + [Enter]

Parameters:

EDID Mode Commands

Some available formulas for EDID Mode commands are as follows:

Command + Control + [Enter]

To set the remix EDID setting, type the following:

edid remix [Enter]

To enable the EDID of the display connected to console 1, type the following:

edid port1 [Enter]

Command Description

edid EDID Mode Command

Control Description

remix Implement the EDID of each connected

display according to its connection when the

CS261 is first powered on, or immediately

after selecting the Remix option.

port1 Implement the EDID of the connected

display to console1, and pass it to the

source.

default 720p Implement s ATEN’s EDID

1280x720@60Hz.

default 1600 Implement s ATEN’s EDID

1600x1200@60Hz.

default 1080p Implement s ATEN’s EDID

1920x1080@60Hz.

Enter Description

Enter Enter and send out command
