CE610 User Manual
2
Features
Uses a single Cat 5e cable to connect the local and remote units
Allows access to a computer or KVM installation from a remote console
Superior Video Quality – up to 1920 x 1200 @ 60 Hz at 100 m
Supports HDBaseT connectivity technology
Transparent USB Support – supports all USB 2.0 High Speed device*
Extends local PC Video/Keyboard/Mouse to Remote side
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage
15KV)
ExtremeUSB® - supports transparent USB 2.0 signals and true plug-and-
play (no software or drivers required)
USB 2.0 Support* – connects devices such as keyboard, mouse, flash
drive, printer, touch panel, USB 1.1 web cameras and other USB devices
which require moderate amounts of bandwidth
Works with all major operating systems: Windows®, OS X®, and Linux®
*Note: The CE610 supports a maximum combined USB transfer rate of 30
Mbps for attached USB devices.
