9
Chapter 3
Operation
Overview
The VC182 VGA to HDMI Converter with Scaler offers easy and flexible
operation through its built-in On-Screen Display (OSD) and the Utility Tool,
which can be installed on a computer connected to the VC182’s mini USB port.
On-Screen Display (OSD)
The built-in OSD can be configured using the VC182 front panel pushbuttons,
as follows:
Menu pushbutton – opens the OSD and selects menu options
Up / Down pushbuttons – navigates the OSD menu and lists of options
You can cycle through the Menu options in the order shown in the table below.
OSD Menu
Output Setup Output Resolution
Output Mode
Default Pattern
Audio Source
Image Contrast
Brightness
Saturation
Hue
B/W Extension
Color Tone
Edge Enhance
Sharpness
Under/Over ScanAdjustment
Aspect Ratio
H-Mirror
V-Mirror
H-Shift
V-Shift
System Input Resolution Info
F/W Version
Factory Reset
