Aten VC182 [32/33] Specifications

VC182 User Manual

Specifications

Function VC182

Connectors

Input Video In

1 x HDB-15 female (Black)

Digital Coaxial Audio

1 x RCA female (Yellow)

Analog Stereo Audio

1 x Mini Stereo jack (Black)

Output HDMI Out

1 x HDMI Type A female

Power Jack 1 x DC jack

Firmware Upgrade 1 x Mini USB port

Switches Down 1 x Pushbutton

Up 1 x Pushbutton

Menu 1 x Pushbutton

Firmware Upgrade 1 x Dip switch

LEDs Signal 1 (Green)

Power 1 (Red)

Video 1080p; 1920 x 1200

Power Consumption DC 5V, 5W

Environment Operation Temperature 0 - 40°C

Storage Temperature -20°C - 60°C

Humidity 20 – 90% RH, Non-condensing

Physical

Properties

Housing Metal

Weight 0.31 kg

Dimension (L x W x H) 11.00 x 8.30 x 2.80 cm
