Chapter 3
A75F2-A2 USER MANUAL
39
fParallel Port Configuration
Scroll to this item and press <Enter> to view the following screen:
Parallel Port (Enabled)
This item allows you to enable or disable parallel port.
Device Settings (IO=378h; IRQ=5)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.
Device Mode (Standard and Bi-dir...)
This item shows the information of the device mode.
Press <Esc> to return to the Super IO Configuration page.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Parallel Port Configuration
Parallel Port Enabled
Device Settings IO=378h; IRQ=5
Change Settings
Auto
Device Mode Standard and Bi-dir...
lk
: Select Screen
+/- : Change Opt.
Enter/Dbl Click : Select
mn
F1: General Help
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
F2: Previous Values
Enabled or Disabled Parallel
Port (LPT/LPTE)
