A75F2-A2 USER MANUAL

Chapter 1

System BIOS

Form Factor

• ATX Size, 305mm x 210mm

• AMI BIOS with 32Mb SPI Flash ROM

• Support Multi-language BIOS Utility

• Support Over-Clocking

• Support eBLU, eDLU, eOC, eSF

• Support ECS M.I.B III Utility

• Support EZ Charger
