Chapter 2

Q77H2-TI USER MANUAL

No. Components

1LCD_SEL

2CLR_CMOS

3ME_UNLOCK

This section explains how to set jumpers for correct configuration of the

motherboard.

2-3. Checking Jumper Settings

1. LCD_SEL: LCD panel select header (optional)

1.When your panel connects to LVDS, please check LCD_SEL header setting

first.

2.Due to the differences of the panel parameters, please follow the above

illustration to place the jumper caps.
