Chapter 3
Q77H2-TI USER MANUAL
57
This page enables you to set the keyboard NumLock state.
Boot Menu
Boot Configuration
This item shows the information of the Boot Configuration.
Operation System Select (Windows 7 or other OS)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot (Enabled)
Use this item to enable or disable quiet boot.
Boot mode select (LEGACY)
Use this item to select boot mode.
Set Boot Priority
This item enables you to set boot priority for all boot devices.
Boot Option #1 /
2 /3 /4 /5 /6 /7
These items show the boot priorities.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Windows 7 or Other OS: Boot policy
for Legacy OS.
Windows 8: Boot policy for UEFI OS
without Compatibility Support
Module(CSM).
Manual: User customized CSM
parameters & boot policy.
Main Advanced Chipset Tweak Boot Security Exit
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Boot Configuration
Operating system select [Windows 7 or othre OS]
Launch PXE OpROM [Disabled]
Launch Storage OpROM [Enabled]
Bootup NumLock State [On]
Quiet Boot [Enabled]
Boot mode select [LEGACY]
Set Boot Priority
Boot Option #1 [Hard Disk]
Boot Option #2 [CD/DVD]
Boot Option #3 [USB/Floppy]
Boot Option #4 [USB CD/DVD]
Boot Option #5 [USB Hard Disk]
Boot Option #6 [USB Flash]
Boot Option #7 [Network]
