Chapter 3
Q77H2-TI USER MANUAL
39
Limit CPUID Maximum (Disabled)
Use this item to enable or disable the maximum CPUID value limit, you can enable
this item to prevent the system from “rebooting” when trying to install Windows NT
4.0.
CPU Configuration
The item in the menu shows the CPU Configuration.
Intel(R) Celeron(R) CPU G530T @ 2.00GHz
This is display-only field and diaplays the information of the CPU installed in your
computer.
EM64T (Supported)
This item shows the computer supports EMT64.
Processor Speed (2000MHz)
This item shows the current processor speed.
Processor Stepping (206a7)
This item shows the processor stepping version.
Microcode Revision (28)
This item shows the Microcode version.
Processor Cores (2)
This item shows the core number of the processor.
Intel HT Technology (Not Supported)
This item shows that the computer supports Intel HT Technology or not.
Intel VT-x Technology (Supported)
This item shows that the computer supports Intel VT-x Technology or not.
CPU Configuration
Intel(R) Celeron(R) CPU G530T @ 2.00GHz
EMT64 Supported
Processor Speed 2000 MHz
Processor Stepping 206a7
Microcode Revision 28
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Limit CPUID Maximum [Disabled]
Execute Disable Bit [Enabled]
Intel Virtualization Technology [Enabled]
CPU C3 Report [Enabled]
CPU C6 Report [Enabled]
Enhanced Halt (ClE) [Enabled]
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Disabled for Windows XP
Main Advanced Chipset Tweak Boot Security Exit
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
