Using BIOS
ACPI Configuration
The item in the menu shows the highest ACPI sleep state when the system enters
suspend.
ACPI Sleep State (S3(Suspend to RAM))
This item allows user to enter the ACPI S3 (Suspend toRAM) Sleep State (default).
Press <Esc> to return to the Advanced Menu page.
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
ACPI Settings
ACPI Sleep State [S3 (Suspend to RAM)]
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Select the highest ACPI sleep
state the system will enter
when the SUSPEND button is
pressed.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset M.I.B III Boot Security Exit
ff
ff
f
