40
Using BIOS
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Configuration
SATA Mode [IDE Mode]
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
SATA Port5 Not Present
SATA Port6 Not Present
+/- : Change Opt.
lk
mn
:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enter : Select
Determines how SATA
controller(s) operate.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port1~6
This motherboard supports six SATA channel and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
Press <Esc> to return to the Advanced Menu page.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main
Advanced Chipset M.I.B III Boot Security Exit
ff
ff
f
