45
Using BIOS
The chipset menu items allow you to change the settings for the North chipset,
South chipset and other system.
Chipset Menu
f System Agent Configuration
Scroll to this item and press <Enter> and view the following screen.
Initate Graphic Adapter (Auto)
This item allows you to select graphics controller to use as the primary boot device.
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
System Agent (SA) Parameters
System Agent Configuration
PCH Configuration
ME Configuration
f
f
f
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Select which of IGFX/PEG/PCI
Graphics device should be Primary
Display or select SG for Switchable
Gfx.
System Agent Configuration
Initate Graphic Adapter [Auto]
IGD Memory [64M]
DVMT Memory [256M]
IGD Multi-Monitor [Disabled]
IGD Memory (64M)
This item shows the information of the IGD(Internal Graphics device) memory.
DVMT Memory (256M)
When set to Fixed Mode, the graphics driver will reserve a fixed position of the
system memory as graphics memory, according to system and graphics requirements.
IGD Multi-Monitor (Disabled)
This item enables or disables IGD(Internal Graphics device) multi-monitor.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit
