52
Using BIOS
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
M.I.B III (MB Intellient BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology [Enabled]
Auto Detect DIMM/PCI Clk [Enabled]
Spread Spectrum [Enabled]
CPU Voltage [Auto]
IMC Voltage [Auto]
DIMM Voltage [Auto]
PCH Voltage [Auto]
Intel(R) Core(TM) i5-2400 CPU @ 3.10GHz
Processor Speed 3000 MHz
Memory Frequency 1333 MHz
Total Memory 2048 MB (DDR3)
CPU Current Voltage 1.200V
IMC Current Voltage 1.044V
DIMM Current Voltage 1.524V
+/- : Change Opt.
lk
mn
:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enter : Select
CPU OverClocking Configuration
f
f
fCPU OverClocking Configuration
Scroll to this item to view the following screen:
Enhanced Intel SpeedStep
Technology
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
CPU OverClocking Configuration
CPU Frequency (1/100 MHz) 10000
CPU Ratio 30
Enhanced Intel SpeedStep Technology [Enabled]
CPU Ratio (30)
This item allows users to control non turbo CPU ratio.
CPU Frequency (1/100MHz)
This item shows the information of the CPU frequency.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset
M.I.B III Boot Security Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced Chipset
M.I.B III Boot Security Exit
