11
G
B
Before using the compressor, read the instructions for use carefully and
comply with the following safety precautions. Consult this handbook if
you have any doubts regarding functioning.
Preserve all the documentation so that anyone who uses the
compressor can consult this beforehand.
SAFETY RULES
1
This symbol indicates warnings to be read before using the product so as
to prevent injury to the user.
Compressed air is a potentially dangerous form of energy; always take
great care when using the compressor and its accessories.
Warning: the compressor may restart when power is restored following
a blackout.
An ACOUSTIC PRESSURE value of 4 m. corresponds to the ACOUSTIC
POWER value stated on the yellow label located on the compressor,
minus 20 dB.
THINGS TO DO
● The compressor must be used in a suitable environment (well
ventilated with an ambient temperature of between +5°C and +40°C)
and never in places affected by dust, acids, vapors, explosive or
flammable gases.
● Always maintain a safety distance of at least 4 meters between the
compressorandtheworkarea.
● Any coloring of the belt guards of the compressor during painting operations
indicatesthatthedistanceistooshort.
● Insert the plug of the electric cable in a socket of suitable shape, voltage
andfrequencycomplyingwithcurrentregulations.
● Use extension cables with a maximum length of 5 meters and of suitable
cross-section.
● Theuseofextensioncablesofdifferentlengthandalsoofadaptersand
multiplesocketsshouldbeavoided.
● Always use the switch I/O toswitchoffthecompressor.
● Alwaysusethehandletomovethecompressor.
● When operating, the compressor must be placed on a stable, horizontal
surface.
THINGS NOT TO DO
● Neverdirectthejetofairtowardspersons,animalsoryourbody.(Always
wear safety goggles to protect your eyes against flying objects that may be
liftedbythejetofair).
● Never direct the jet of liquids sprayed by tools connected to the compressor
towardsthecompressor.
● Neverusetheappliancewithbarefeetorwethandsorfeet.
● Never pull the power cable to disconnect the plug from the socket or to
movethecompressor.
● Neverleavetheapplianceexposedtoadverseweatherconditions.
● Nevertransportthecompressorwiththereceiverunderpressure.
● Donotweldormachinethereceiver.Inthecaseoffaultsorrusting,replace
theentirereceiver.
● Neverallowinexpertpersons tousethecompressor.Keepchildrenand
animalsatadistancefromtheworkarea.
●Thisapplianceisnotintendedforusebypersons(includingchildren)with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their
safety.
● Children should be supervised to ensure that they do not play with the
appliance.
● Donotpositionflammableornylon/fabricobjectsclosedtoand/oronthe
compressor.
● Nevercleanthecompressorwithflammableliquidsorsolvents.Checkthat
youhaveunpluggedthecompressorandcleanwithadampclothonly.
● Thecompressormust beusedonlyforaircompression.Do notusethe
compressorforanyothertypeofgas.
● The compressed air produced by the compressor cannot not be used
for pharmaceutical, food or medical purposes except after particular
treatmentsandcannotbeusedtofilltheairbottlesofscubadivers.
THINGS YOU SHOULD KNOW
●
To avoid overheating of the electric motor, this compressor is
designed for intermittent operation as indicated on the technical
dataplate(forexample,S3-25means2.5minutesON,7.5minutesOFF).In
the case of overheating, the thermal cutout of the motor trips, automatically
cuttingoffthepowerwhenthetemperatureistoohigh.Themotorrestarts
automaticallywhennormaltemperatureconditionsarerestored.
● All the compressors are fitted with a safety valve that is tripped in the case
ofmalfunctioningofthepressureswitchinordertoassuremachinesafety.
● Whenfittingatool,theflowofairinoutputmustbeswitchedoff.
●Therednotch on the pressure gauge refers to the maximum operating
pressureofthetank.Itdoesnotrefertotheadjustedpressure.
● When using compressed air, you must know and comply with the safety
precautionstobeadoptedforeachtypeofapplication(inflation,pneumatic
tools,painting,washingwithwater-baseddetergentsonly,etc.).
●Donotcovertheairinletsonthecompressor.
●Do not open or tamper with any part of the compressor. Contact an
authorizedServiceCenter.
ASSEMBLY
2
You must fully assemble the appliance before using it for the first time.
Fitting the wheels
FitthesuppliedwheelsasshowninFig.2and3:
● Fig.2a&2b:Assemblyofwheelkit-versionA
Assembly by sequence: a, b, c, d, e
● Fig.3a&3b:Assemblyofwheelkit-versionB
Fitting the rubber foot
FitthesuppliedrubberstopperasshowninFig.4.
START-UP AND USE
3
● Check for correspondence between the compressor plate data with the
actual specifications of the electrical system.Avariation of ± 10% with
respectoftheratedvalueisallowed.
● Insert the plug of the power cable in a suitable socket checking that the I/O
switchlocatedonthecompressorisintheOFF«O»position.
● Atthispoint,thecompressorisreadyforuse.
● Operating on the I/O switch, the compressor starts, pumping air into the
receiverthroughthedeliverypipe.
● When the upper calibration value (set by the manufacturer) has been
reached,thecompressorstops.
When air is used, the compressor restarts automatically when the lower
calibrationvalueisreached(2barbetweenupperandlower).
● Thepressureinthereceivercanbecheckedonthegaugeprovided.
● Thecompressor continues to operate according to this automatic cycle
until the I/Oswitchisturned.
● Always wait at least 10 seconds from when the compressor has been
switchedoffbeforerestartingthis.
● Allcompressorsarefittedwithapressurereducer(ref.7).Operatingonthe
knobwiththetapopen(turningitinaclockwisedirectiontoincreasethe
pressureandinacounterclockwisedirectiontoreduceit),airpressurecan
be regulated so as to optimize use of pneumatic tools.
● Thevaluesetcanbecheckedonthegauge(ref.6).
●Thesetpressurecanbetakenfromthequicklockcoupling(ref.5).
● Please check that the air consumption and the maximum working
pressure of the pneumatic tool to be used are compatible with the
pressure set on the pressure regulator and with the amount of air
supplied by the compressor.
● Always pull out the plug and drain the receiver once you have completed
yourwork.
Preserve this handbook for future reference
COMPONENTS (fig. 1 - 2 - 3 - 4)
1. Shroud 10. Safety valve
2. Pressurevessel(tank) 11. Receiver condensation drainage tap
3. Wheel 12.
Pressuregauge(forreadingthetank
pressure)
4. Rubber foot 13. Axle
5.
Quick-lockcoupling(regulated
compressedair)
14. Clip
6.
Pressuregauge(forreadingthepreset
pressurebymeansofregulator)
15. Screw
7. Pressure regulator 16. Nut
8. I/O switch 17. Washer
9. Transportationhandle
