Gorenje DF6115E [10/96] Electrical connection

Installation

The minimum distance between the supporting surface for the

cooking equipment on the hob and the lowest part of the

range hood must be not less than 60cm from electric cookers

and 70cm from gas or mixed cookers.

If the instructions for installation for the gas hob specify a

greater distance, this must be adhered to.

Electrical connection

The mains power supply must correspond to the rating

indicated on the plate situated inside the hood. If provided with

a plug connect the hood to a socket in compliance with current

regulations and positioned in an accessible area. If it not fitted

with a plug (direct mains connection) or if the plug is not

located in an accessible area apply a double pole switch in

accordance with standards which assures the complete

disconnection of the mains under conditions relating to over-

current category III, in accordance with installation

instructions.

Warning! Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that

the mains cable is correctly assembled.

Mounting

Before beginning installation:

• Check that the product purchased is of a suitable size for

the chosen installation area.

• To facilitate installation, remove the fat filters and the

other parts allowed and described here, dismantle and

mount it.

To remove see also the relative paragraphs.

• Remove the active carbon (*) filter/s if supplied (see also

relative paragraph). This/these is/are to be mounted only

if you want lo use the hood in the filtering version.

• Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with

screws (*), guarantees (*), etc.), eventually removing

them and keeping them.

• If possible, disconnect and move freestanding or slide-in

range from cabinet opening to provide easier access to

rear wall/ceiling. Otherwise put a thick, protective

covering over countertop, cooktop or range to protect

from damage and debris. Select a flat surface for

assembling the unit. Cover that surface with a protective

covering and place all canopy hood parts and hardware

in it.

• In addition check whether near the installation area of the

hood (in the area accessible also with the hood mounted)

an electric socket is available and it is possible to

connect a fumes discharge device to the outside (only

suction version).

• Carry out all the masonry work necessary (e.g.

installation of an electric socket and/or a hole for the

passage of the discharge tube).

Preliminary information for installation of the hood:

Attention! The 2 fixing brackets are lodged in the protection

in polyester packing

The brackets are one right R and one left L (see bossing

shown on the brackets).

1. Fix the D bracket (Fig.1) to the side panel of the wall unit

with two screws for every bracket (the right R bracket on

the right side and the left L bracket on the left side).

Align the bracket with the lower border.

Position the bracket to touch the back border of the wall

cabinet, considering that the back border of the bracket

corresponds to the back side of the cooker hood;

If the cooker hood is provided with a spacer, in case of

use, move the bracket forward to the same thickness as

the spacer.

Drill a hole on the ceiling of the wall cabinet to pass the

discharge tube and the electrical cable (the quote

indicated in Fig. 1 does not include the eventual spacer).

2. If not already mounted, fix the two E brackets (Fig.2) to

the sides of the hood (one per side).

a. remove the extractable part of the cooker hood;

b. remove the grease filter/s;

c. fix the brackets with two screws P per bracket from

inside the cooker hood, affix them as more as possible

upwards (air exit side) and then serrate the screws.

3. Affix the spacer M with three Clips from the external part

of the cooker hood (if supplied - Fig. 2).

4. Insert the cooker hood in the wall cabinet, ensuring to

position the cooker hood bracket E above the wall

cabinet bracket D (Fig. 3).

Thread the electric cable through the appropriate

perforation.

5. Block the cooker hood with two screws on the frontal part

(Fig. 3 – one per side).

6. Connect the cable to the electrical mains, only when the

installation is completed.

7. If the cooker hood should not touch perfectly with the

lower border of the wall cabinet then regulate by

loosening the screws P of the brackets E mounted on the

cooker hood (Fig. 2), it will be possible to regulate the

perfect matching of the cooker hood and wall cabinet,

once regulated tighten the screws.

8. Regulate the gliding of the extractable drawer in relation

to the depth of the wall cabinet by acting on the two

skirting boards F (Fig. 4).

In this way it will be possible to place the front in line with

the wall cabinet (Fig. 4).

a. Loosen the screws on the skirting board F;

b. Move the ledges backwards or forwards depending on

requirement.

c. Lock in the screws on the ledges.

9. Install a discharge tube on the connection ring C

supplied, preferably with a diameter equivalent to the

connection ring (Fig. 5). the discharge tube should be

sufficiently long to reach outside (Suction version) or the

ceiling of the wall cabinet (Filter version).

10. Fix the connection ring C (snap into place), at the upper

exit of the cooker hood.

To ease the installation, the ring is equipped with an

index G that should correspond to the appropriate guide

H placed on the upper air exit.
