11
Operation
is completed.
• All the function buttons do not operate.
• Error symbol on the display.
AUX in jack
AUX-in jack is intended for connecting an
external audio or video equipment to amplify
the sound. If connection is made correctly, the
audio signal from the external source will be
translated through the acoustics of the head
unit. This enables to adjust the volume and
quality of the sounding. For example, you can
connect an MP3-player to listen to tracks using
the car acoustic system.
Radio operations
BAND selection
Press repeatedly BAND button to select
your desired radio band in radio mode: FM1,
FM2, FM3, MW. Each band can store 6 preset
stations, for a total of 24 preset memory stations.
Tuning
Press PREV or NEXT button; the unit will
automatically search a nearest station with a
strong signal. To search next station repeat
this procedure. To stop the automatical search,
press PREV or NEXT button.
Press and hold PREV or NEXT button to
activate manual search mode. Press PREV/
NEXT buttons to search for a station manually
(MANUAL will be displayed). If you don’t press
any button within several seconds, the unit will
return to auto search mode.
Automatic store/Scan
• Automatic store: Press and hold AMS
button, the receiver will automatically scan and
save stations for the current band.
• Scan: Press AMS button once to scan the
saved stations in each band.
Programming stations
There are six numbered preset buttons,
under which you can store and recall stations
for each band. Select the needed station,
then press and hold a preset button. The
station will be saved in the memory under
the corresponding number. To recall a stored
station, press the corresponding preset button.
RDS function
RDS (Radio Data System) service availability
varies with areas. Please understand if RDS
service is not available in you area, the
following service is not available, either.
AF (Alternative Frequencies)
function
Press REG/AF button to turn the AF function
on or off.
When the radio signal strength is poor,
enabling the AF function will allow the unit to
automatically search another station with the
same PI (Program Identification) as the current
station but with stronger signal strength, so that
you do not have to retune the stations when
driving between different transmitter coverage
areas. When AF symbol is on, it means RDS
information is received; when AF symbol is
flashing, it means RDS information is not yet
received.
PS (Program Service name): the name of
station will be display instead of frequency.
If RDS service is not available in your area,
turn off the AF mode. Default setting is ON.
Program name is displayed on receiving
a RDS station. “ALARM” will be displayed
when an emergency broadcasting is received;
meanwhile sound output level will be adjusted
to the preset output level automatically when
the volume control is set at minimum.
REGIONAL ON/OFF mode
Press and hold REG/AF button, REGION
ON/OFF mode is selected.
REG ON: AF switching or PI SEEK is
implemented to the station which have all PI
codes are same as current station (PI CODE is
checked when AF CHECK in progress)
REG OFF: The regional code in the format
