12 13
Operation Operation
of PI code is ignored when AF switching or
PI SEEK is implemented. (PI CODE and
COVERAGE AREA is not checked when AF
CHECK in progress)
TA (Traffic Alarm) function
Press TA button to turn TA function on or off.
In TA mode traffic program will be
automatically searched, until the program
is received. When traffic announcement is
received the unit will temporarily switch to the
tuner mode (regardless of the current mode)
and begin broadcasting the announcement.
After the traffic announcement is over, it will
return to the previous mode and volume level.
To interrupt traffic announcement press TA
button shortly; it will not switch off the TA mode.
PTY (Program Type)
This radio will allow you to select the type of
program required, and will search for a station
broadcasting that type of program.
Press PTY button to show the music type.
Then press 1 - 6 number buttons to choose
different music programs available.
Press PTY button twice to show the speech
type program. Then press 1 - 6 number buttons
to choose different speech programs. Each
number button will show 3 different speech
programs for you to choose (see table below).
Button Music group Speech group
1 Pop, Rock News, Affairs,
Info
2 Easy, Light Sport, Educate,
Drama
3 Classics Culture, Science,
Varied
4 Jazz, Country Weather,
Finance, Children
5 Nation, Oldies Social, Religion,
Phone IN
6 Folk Travel, Leisure,
Document
When PTY is selected, the radio starts to
search corresponding PTY information, and
stops if the corresponding PTY information
is detected. If no buttons are pressed within
several seconds, previously selected PTY is
searched. During 1 loop, if desired PTY is not
found, the unit will return to previous mode.
Press PTY button for the 3rd time to switch the
PTY function off.
Local/distant stations
Press TA button for several seconds, to select
EON ТА LOCAL/EON TA DISTANCE mode.
If you want to receive information from local
stations only, select EON ТА LOCAL mode.
Otherwise, select EON TA DISTANCE mode.
Other parameter setting
To choose the corresponding parameter,
press and hold SEL button, then press it
repeatedly until the display shows the needed
parameter. Turn VOL knob to choose the
needed value. After choosing, please leave the
unit idle to activate.
TA SEEK/TA ALARM
When newly tuned station does not receive
TP information for 5 seconds, the radio
retunes to next station which has not the same
station (PI – Program Information) as the last
station, but has the TP information. When TP
information gets lost at the current station for
retune time which is set by RETUNE SHORT
(30 seconds) or RETUNE LONG (90 seconds),
the radio starts to retune to next same PI
station. When same PI station does not catch in
1 cyclic search, the radio retunes to next station
with TP information. In TA SEEK mode, the
unit will seek for traffic announcement program
when TA button is pressed; in TA ALARM the
unit does not retune to TA information.
PI SOUND/MUTE
Choose PI sound or mute. PI sound refers to
the reception noise when the AF function tries
to scan alternative frequency.
RETUNE S/L - SHORT/LONG
“RETUNE” refers to the time period the
unit allows for radio scan when reception is
