7
Installation/Connection
Location Function
Connector A Connector B
1 Rear Right(+)---Violet
2 Rear Right(-)---Violet/Black
3 Front Right(+)---Grey
4 Battery 12V (+)/yellow Front Right(-)---Grey/Black
5 Antenna control/blue Front Left(+)---White
6 Front Left((-)---White/Black
7 ACC+/red Rear Left(+)---Green
8 Ground/black Rear Left(-)---Green/Black
Power antenna wire is intended for
power supply of the antenna and for remote
control of an additional amplifier.
