![Hyundai H-CDM8017G Black [14/39] Operation](/views2/1021448/page14/bge.png)
14
Operation
PREV or TA 8
NEXT or AF 9
DISP or POWER 0
After inputting the track unber, press BAND
button to start playback.
Mixed CD operations
The unit can play the mixed-CD disc (when
disc contains both CD audio tracks and MP3/
WMA files).
When you insert a mixed-CD disc into the
CD slot, it starts to play the CD audio tracks.
If you want to play MP3/WMA files, press 5
button or 6 button, it will search the disc over
and start to play the MP3 files.
If you want to return to CD mode, press 5
button or 6 button, it will search the disc over
and start to play the CD audio track.
Notes on MP3 and WMA
• MP3 is short for MPEG Audio Layer 3
and refers to an audio compression technology
standard.
• This product allows playback of MP3 files
on CD-ROM, CD-R or CD-RW discs.
• The unit can read MP3 files written in the
format compliant with ISO 9660. However it
does not support the MP3 data written by the
method of packet write.
• The unit can not read an MP3 file that has
a file extension other than “.mp3”.
• If you play a non- MP3 file that has the
“.mp3” extension, you may hear some noise.
• In this manual, we refer to what are called
“MP3 file” and “folder” in PC terminology as
“track” and “album”, respectively.
• Maximum number of directory level is 8,
including the root directory. Maximum number of
files and folders per disc is 256.
• The unit may not play tracks in the order
of Track numbers.
• The unit plays only the audio tracks if a
disc contains both audio tracks and MP3 files.
• When playing a disc of 8 kbps or “VBR”,
the elapsed playing time in the display window
will not be correct and also the intro play may
not function properly. “VBR”: Variable Bit Rate.
• The unit supports the playback of WMA
files. The playback of ID3 tags for WMA format
is not guaranteed, it depends on versions and
availability of Cyrillic alphabet.
• WMA (Windows Media Audio) – music
data compression format, created by Microsoft
Corporation. This format uses coding algorithm
for compression of initial audio-record, greatly
decreasing the file size, but, saving the good
sound quality even when the bit rate is low (for
example, 64 Kbit/s).
• Remember that the unit may not play the
tracks in order they are written on disc.
Notes on creating your own CD-Rs
or CD-RWs containing MP3 files
• To enjoy high quality sound, we
recommend converting to MP3 files with a
sampling frequency of 44.1 kHz and a fixed bit
rate o f 128 kbps.
• Do not store more than 256 MP3 files per
disc.
• For ISO 9660 - compliant format, the
maximum allowable depth of nested folders is
8, including the root directory (folder).
• When CD-R disc is used, playback is
possible only for discs, which have been
finalized.
• Make sure that when MP3 CD-R or CD-
RW is burned that it is formatted as a data disc
and not as an audio disc.
• You should not write non-MP3 files or
unneeded folders along with MP3 files on the
disc otherwise it takes a long time until the unit
starts to play MP3 files.
• With some CD-R or CD-RW media, data
may not be properly written depending on their
manufacturing quality. In this case, data may
not be reproduced correctly. High quality CD-R
or CD-RW disc is recommended.
• Up to 16 characters are displayed for the
name of an Album or a Track. ID3TAG version
1.x is required.
• Note that the unit may not play tracks in
the order that you wrote them to the disc.
