Hitachi DS9DVF3 [15/96] English

English

10. Using the hook

CAUTION

䡬 When using the hook, pay sufficient attention so

that the main equipment does not fall. If the tool

falls, there is a risk of accident.

䡬 Do not attach the tip tool except phillips bit to the

tool main unit when carrying the tool main unit with

the hook suspended from a waist belt.

Injury may result if you carry the equipment

suspended from the waist belt with sharp tipped

components such as drill bit attached.

The hook can be installed on the right or left side and

the angle can be adjusted in 5 steps between 0° and

80°.

(1) Operating the hook

(a) Pull out the hook toward you in the direction

of arrow (A) and turn in the direction of arrow

(B) (Fig. 12).

(b) The angle can be adjusted in 5 steps (0°, 20°,

40°, 60°, 80°).

Adjust the angle of the hook to the desired

position for use.

(2) Switching the hook position

CAUTION

Incomplete installation of the hook may result in

bodily injury when used.

(a) Securely hold the main unit and remove the

screw using a slotted head screwdriver or a coin

(Fig. 13).

(b) Remove the hook and spring (Fig. 14).

securely fasten with screw (Fig. 15).

NOTE

Pay attention to the spring orientation. Install the

spring with larger diameter away from you (Fig. 15).

(3) Using the bit holder (Hook with bit holder)

䡬 Installing the bit

Slide the bit from the side and then insert firmly

until the groove on the bit locks in the protruded

section of the hook.

䡬 Removing the bit

Securely hold the main unit and pull out the bit

by holding the tip with your thumb (Fig. 16).

CAUTION

䡬 Only Hitachi STANDARD ACCESSORIES phillips bit

(No. 2 × 65L; Code No. 983006) may be used. Do

not use other bits since they may come loose.

(4) Using as an auxiliary light (Hook with light)

(a) Press the switch to turn off the light.

If forgotten, the light will turn off automatically

after 15 minutes.

(b) The direction of the light can be adjusted within

the range of hook positions 1 - 5 (Fig. 17).

䡬 Lighting time

AAAA manganese batteries: approx. 15 hrs.

AAAA alkali batteries: approx. 30 hrs.

CAUTION

Do not look directly into the light.

Such actions could result in eye injury.

(5) Replacing the batteries

(a) Loosen the hook screw with a phillips-head

screwdriver (No. 1) (Fig. 18).

Remove the hook cover by pushing in the

direction of the arrow (Fig. 19).

CAUTION

䡬 The selection examples shown in Table 7 should

be considered as general standard. As different

types of tightening screws and different materials

to be tightened are used in actual works proper

adjustments are naturally necessary.

䡬 When using the driver drill with a machine screw

at HIGH (high speed), a screw may damage or a

bit may loose due to the tightning torque is too

strong. Use the driver drill at LOW (low speed)

when using a machine screw.

6. Mounting and dismounting of the bit

(1) After inserting a driver bit, etc. into the keyless drill

chuck, firmly grasp the ring and tighten the sleeve

by turning it toward the right (in the clockwise

direction as viewed from the front) (See Fig. 9).

䡬 If the sleeve becomes loose during operation, tighten

it further. The tightening force becomes stronger

when the sleeve is tightened additionally.

(2) Dismounting the bit

Firmly grasp the ring and loosen the sleeve by

turning it toward the left (in the counter-clockwise

direction as viewed from the front) (See Fig. 9).

(1) Mounting the bit

Loosen the sleeve by turning it toward the left (in

the counterclockwise direction as viewed from the

front) to open the clip on the keyless chuck. After

inserting a driver bit, etc., into the keyless drill

chuck, and tighten the sleeve by turning it toward

the right (in the clockwise direction as viewed from

the front) (See Fig. 10).

䡬 If the sleeve becomes loose during operation, tighten

it further.

The tightening force becomes stronger when the

sleeve is tightened additionally.

(2) Dismounting the bit

Loosen the sleeve by turning it toward the left (in

the counterclockwise direction as viewed from the

front), and then take out the bit, etc (See Fig. 10).

CAUTION

䡬 When it is no longer possible to loosen the sleeve,

use a vise or similar instrument to secure the bit. Set

the clutch mode between 1 and 11, and then turn

the sleeve to the loose side (left side) while operating

the clutch. It should be easy now to loosen the sleeve.

7. Confirm that the battery is mounted correctly

8. Check the rotational direction

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the selector button.

The L-side of the selector button is pushed to turn

the bit counterclockwise (See Fig. 11) (The

and

marks are provided on the body).

9. Switch operation

䡬 When the trigger switch is depressed, the tool

rotates. When the trigger is released, the tool stops.

䡬 The rotational speed of the drill can be controlled by

varying the amount that the trigger switch is pulled.

Speed is low when the trigger switch is pulled slightly

and increases as the trigger switch is pulled more.

NOTE

䡬 A buzzing noise is produced when the motor is about

to rotate; This is only a noise, not a machine failure.

01Eng_DS9DVF3_EE 1/20/09, 16:0014
