Gigabyte GA-A320M-HD2 [6/38] 2 product specifications
![Gigabyte GA-A320M-HD2 [6/38] 2 product specifications](/views2/1233057/page6/bg6.png)
1-2 ProductSpecications
CPU AM4 Socket:
- AMDRyzen
™
processor
- AMD 7th Generation A-series/Athlon
™
processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD A320
Memory 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR4 2667
(Note)
/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor:
- 1xD-Subport,supportingamaximumresolutionof1920x1200@60Hz
- 1xDVI-Dport,supportingamaximumresolutionof1920x1200@60Hz
* The DVI-D port does not support D-Sub connection by adapter.
- 1xHDMIport,supportingamaximumresolutionof4096x2160@24Hz
* Support for HDMI 1.4 version.
Support for up to 3 displays at the same time
Maximum shared memory of 2 GB
Audio Realtek
®
ALC887 codec
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out
LAN Realtek
®
GbE LAN chip(10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
(Note)
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
2 x PCI Express x1 slots
(The PCI Express x1 slots conform to PCI Express 2.0 standard.)
1 x PCI slot
Storage Interface 4 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
USB Chipset:
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 2 x USB 3.1 Gen 1 ports available through the internal USB headers
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
CPU:
- 3 x USB 3.1 Gen 1 ports on the back panel
(Note) Actual support may vary by CPU.
- 6 -
