ROG STRIX X299-E GAMING
1-25
Chapter 1
11. RGB header (4-pin RGB_HEADER1, RGB_HEADER2)
TheseconnectorsareforRGBLEDstrips.
• TheRGBheadersupports5050multi-colorLEDstrips(+12V/G/R/B),withamaximum
powerratingof3A(12V),andnolongerthan3m.
• EnsurethattheRGBLEDextensioncableandtheRGBLEDstripisconnectedinthe
correctorientation,andthe+12Vconnectorisalignedwiththe+12Vheaderonthe
motherboard.
Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched
offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere
damagetothemotherboard,peripherals,orcomponents.
• ActuallightingandcolorwillvarywithLEDstrip.
• ThelightingeffectsmaybecustomizedwiththehelpofAURAsoftware.
• IfyourLEDstripdoesnotlightup,checkiftheRGBLEDextensioncableandthe
RGBLEDstripisconnectedinthecorrectorientation,andthe12Vconnectoris
alignedwiththe12Vheaderonthemotherboard.
• TheLEDstripwillonlylightupwhenthesystemisoperating.
• TheLEDstripsarepurchasedseparately.
